Product Name: CBR-IIIA Digital Display Bearing Ratio Tester
1. Main parameters of the instrument:
2. Test speed: 1 mm/min.
2. Test force: 50 kN, with a force accuracy of 0.001 kN

3. Penetration rod: End diameter Φ50 mm.

4. Displacement sensor: 0–25 mm, resolution: 0.01 mm, linearity: 0.3%.

5. Porous top plate: 1 piece, porous bottom plate: 1 piece.

6. Load plates: 4 pieces (outer diameter Φ150mm, inner diameter Φ52mm, each weighing 1.25kg).

7. Test Cylinder: Inner diameter Φ152 mm, height 170 mm.

8. Power supply voltage: 220V.

9. Net weight: 88 kg

10. Gross weight: 105 kg

II. Key Features of the Bearing Ratio Tester:

1. 5-inch color touchscreen display with data saving and printing capabilities.

2. Equipped with data processing capabilities, it can automatically calculate the CBR value.

3. Built-in mini printer capable of printing data stream lists and test results.

$C:\Users\Administrator\Desktop\d7a2411bbe48edd7e02d81f17367a3c.jpgd7a2411bbe48edd7e02d81f17367a3c$
